Van điện từ/Van điện

Van điện từ / Van động cơ

Giá: Liên hệ

  • Model:

    •

  • Thương hiệu: YOSHITAKE
  • Xuất xứ: Nhật Bản
    • Mô tả sản phẩm Download Catalogue Đánh giá

    Van điện từ / Van động cơ

    DP-10, DP-100, DP-100F, DP-100-C, DP-100F-C, DP-100-D, DP-100F-D, DP-200, DP-200F, DP-200-N, DP-200F-N, DP-12C, DP-12D, DP-12CD, DP-14C, DP-16,  DP-16C, DP-18, DP-18C, DD-2, DD-3, DBLV-2SF, MD-35R, MD-36R, MD-53, MD-54, MD-55, DBFV-1S

    DOWNLOAD CATALOG


    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-10
    DP-10    		 10A -50A
    (3/8"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Bronze

    AC, bronze,

    normally closed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-100
    DP-100    		 10A -50A
    (3/8"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Stainless steel AC, normally closed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-100F
    DP-100F    		 15A -65A
    (1/2"-2-1/2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Stainless steel

    AC, normally closed,

    flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-100-C
    DP-100-C    		 10A -50A
    (3/8"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Stainless steel AC, normally open
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-100F-C
    DP-100F-C    		 15A -65A
    (1/2"-2-1/2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Stainless steel

    AC, normally open,

    flanged



    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-100-D
    DP-100-D    		 10A -50A
    (3/8"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Stainless steel DC, normally closed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-100F-D
    DP-100F-D    		 15A -65A
    (1/2"-2-1/2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Stainless steel

    DC, normally closed,

    flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-200
    DP-200    		 10A -50A
    (3/8"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Bronze

    AC, diaphragm,

    normally closed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-200F
    DP-200F    		 15A -50A
    (1/2"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Bronze

    AC, normally closed,

    flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-200-N
    DP-200-N    		 10A -50A
    (3/8"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Bronze

    AC, normally closed,

    JWWA approved
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-200F-N
    DP-200F-N    		 15A -50A
    (1/2"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Bronze

    AC, normally closed,

    flanged,

    JWWA approved
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-12C
    DP-12C    		 10A -50A
    (3/8"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Bronze

    AC, diaphragm,

    normally open
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-12D
    DP-12D    		 10A -50A
    (3/8"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Bronze

    DC, diaphragm,

    normally closed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-12CD
    DP-12CD    		 10A -50A
    (3/8"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Bronze

    DC, diaphragm,

    normally opened
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-14C
    DP-14C    		 15A -50A
    (1/2"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Bronze

    AC, diaphragm,

    normally open
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-16
    DP-16    		 15A -50A
    (1/2"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Stainless steel

    AC, diaphragm,

    normally closed,

    stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-16C
    DP-16C    		 15A -50A
    (1/2"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa Screwed Stainless steel

    AC, diaphragm,

    normally opened,

    stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-18
    DP-18    		 15A -50A
    (1/2"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 MPa JIS flange_JIS 10K Stainless steel

    AC, diaphragm,

    normally closed,

    stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DP-18C
    DP-18C    		 15A -50A
    (1/2"-2")    		 Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Stainless steel

    AC, diaphragm,

    normally opened,

    stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DD-2
    DD-2    		 10A -20A
    (3/8"-3/4")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 0.8MPa Screwed Stainless steel

    Direct type,

    normally closed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DD-3
    DD-3    		 10A -20A
    (3/8"-3/4")    		 Water
    Oil
    Air,non-dangerous fluids    		 0.8MPa Screwed Stainless steel

    Direct type,

    normally closed,

    FKM disc
    Model Nominal size Application Max. pressure End connection Body Material Feature
    DBLV-2SF
    DBLV-2SF    		 15A -100A
    (1/2"-4")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 Max.1.4MPa JIS flange_JIS 10K
    EN flangeEN PN16
    ASME flange_ASME Class 150    		 Stainless steel

    Electric ball valve,

    ON-OFF, stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    MD-35R
    MD-35R    		 15A -25A
    (1/2"-1")    		 Water
    Air,non-dangerous fluids    		 1MPa Screwed Brass

    Compact 3-way switching

    motor valve
    Model Nominal size Application Max. pressure End connection Body Material Feature
    MD-36R
    MD-36R    		 15A -25A
    (1/2"-1")    		 Water
    Air,non-dangerous fluids    		 1MPa Screwed Brass Compact ON/OFF 2-way valve



    Model Nominal size Application Max. pressure End connection Body Material Feature
    MD-53
    MD-53    		 15A -50A
    (1/2"-2")    		 Water
    Air,non-dangerous fluids    		 1MPa Screwed Stainless steel

    2 way motor valve,

    stainless steel,

    screwed



    Model Nominal size Application Max. pressure End connection Body Material Feature
    MD-54
    MD-54    		 15A -50A
    (1/2"-2")    		 Steam
    Water
    Air,non-dangerous fluids    		 1MPa Screwed Stainless steel

    2-way motor valve,

    screwed, high temp



    Model Nominal size Application Max. pressure End connection Body Material Feature
    MD-55
    MD-55    		 65A -150A
    (2-1/2"-6")    		 Water
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Ductile cast iron

    2-way motor valve,

    ductile iron



    Model Nominal size Application Max. pressure End connection Body Material Feature
    DBFV-1S
    DBFV-1S    		 50A -150A
    (2"-6")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1.9MPa Wafer Stainless steel

    Electric Butterfly valve,

    ON-OFF, Stainless steel
