Van Cơ/Lọc/Kính Quan Sát

Lọc

Giá: Liên hệ

  • Model:
  • Thương hiệu: YOSHITAKE
  • Xuất xứ: Nhật Bản
    • Mô tả sản phẩm Download Catalogue Đánh giá

    Lọc

    SY-5, SY-40, SY-40H, SY-40EN, SY-40C-N, SY-9, SY-17, SY-37, SY-6, SY-6-N, SY-24, SY-24-N, SY-2, SY-8, SY-38, SY-20-10, SY-20-20, SY-10-30, SY-13, SU-20, SU-20S, SU-20C, SU-20H,
    SU-10, SU-10S, SU-50H, SU-50S, ST-10, SU-6, SU-55F, SW-10, SW-10S, ST-1-10,

    DOWNLOAD CATALOG

    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-5
    SY-5    		 10A -50A
    (3/8"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 2MPa Screwed Ductile cast iron Ductile cast iron, Max. 2.0MPa
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-40
    SY-40    		 15A -300A
    (1/2"-12")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K
    Socket weld    		 Ductile cast iron Ductile cast iron, flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-40H
    SY-40H    		 15A -150A
    (1/2"-6")    		 Steam
    Water
    Air,non-dangerous fluids    		 2MPa JIS flange_JIS 20K
    ASME flange_ASME Class 300    		 Ductile cast iron Ductile cast iron, flanged, Max. 2.0MPa
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-40EN
    SY-40EN    		 15A -150A
    (1/2"-6")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 2MPa EN flangeEN PN16
    EN flangeEN PN25    		 Ductile cast iron Ductile cast iron, EN flange
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-40C-N
    SY-40C-N    		 15A -150A
    (1/2"-6")    		 Water
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Ductile cast iron Nylon coating, JWWA approved
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-9
    SY-9    		 15A -50A
    (1/2"-2")    		 Water
    Air,non-dangerous fluids    		 1MPa Screwed Ductile cast iron Easy plug type
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-17
    SY-17    		 15A -50A
    (1/2"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 2MPa Screwed Stainless steel Stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-37
    SY-37    		 15A -50A
    (1/2"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 2MPa Screwed Stainless steel Stainless steel, fine mesh
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-6
    SY-6    		 15A -50A
    (1/2"-2")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1.3MPa Screwed Bronze Bronze, screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-6-N
    SY-6-N    		 15A -50A
    (1/2"-2")    		 Water 1.3MPa Screwed Bronze Bronze (NPb treated), JWWA approved
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-24
    SY-24    		 15A -50A
    (1/2"-2")    		 Water 1.6MPa Screwed Bronze Bronze, Rc x R screwed
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-24-N
    SY-24-N    		 15A -50A
    (1/2"-2")    		 Water 1.6MPa Screwed Bronze Bronze (NPb-treated), Rc x R screwed, JWWA approved
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-2
    SY-2    		 200A
    (8")    		 Steam
    Water
    Air,non-dangerous fluids    		 2MPa JIS flange_JIS 20K Ductile cast iron Ductile cast iron, Max. 2.0MPa, 200A
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-8
    SY-8    		 15A -150A
    (1/2"-6")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 MPa JIS flange_JIS 10K Stainless steel Stainress steel, flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-38
    SY-38    		 15A -150A
    (1/2"-6")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 MPa JIS flange_JIS 10K Stainless steel Stainress steel, flanged, fine mesh
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-20-10
    SY-20-10    		 15A -150A
    (1/2"-6")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Cast carbon steel Carbon steel, 10K flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-20-20
    SY-20-20    		 15A -150A
    (1/2"-6")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 2MPa JIS flange_JIS 20K Cast carbon steel Carbon steel, 20K flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-10-30
    SY-10-30    		 15A -250A
    (1/2"-10")    		 Steam
    Water
    Oil
    Air,non-dangerous fluids    		 3MPa JIS flange_JIS 30K Cast carbon steel Carbon steel, 30K flanged
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SY-13
    SY-13    		 200A -350A and larger
    (8"-14")    		 Steam
    Water
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Carbon steel Carbon steel, large size
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-20
    SU-20    		 20A -150A
    (3/4"-6")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron Ductile cast iron
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-20S
    SU-20S    		 20A -125A
    (3/4"-5")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron Easy maintenance
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-20C
    SU-20C    		 20A -150A
    (3/4"-6")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron Nylon coating
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-20H
    SU-20H    		 200A
    (8")    		 Water
    Oil    		 2MPa JIS flange_JIS 10K
    JIS flange_JIS 20K    		 Ductile cast iron Ductile cast iron, with anchor
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-10
    SU-10    		 20A -150A
    (3/4"-6")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Stainless steel Stainless steel
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-10S
    SU-10S    		 20A -150A
    (3/4"-6")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Stainless steel Stainless steel, easy maintenance
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-50H
    SU-50H    		 50A -150A
    (2"-6")    		 Water
    Oil    		 MPa JIS flange_JIS 20K Ductile cast iron Max. 2.0 MPa
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-50S
    SU-50S    		 50A -150A
    (2"-6")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K
    EN flangeEN PN16    		 Ductile cast iron Easy maintenance
    Model Nominal size Application Max. pressure End connection Body Material Feature
    ST-10
    ST-10    		 125A -250A
    (5"-10")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron Straight type, ductile cast iron
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-6
    SU-6    		 200A -350A and larger
    (8"-14")    		 Water
    Oil    		 MPa JIS flange_JIS 10K Carbon steel Carbon steel, large size
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SU-55F
    SU-55F    		 15A
    (1/2")    		 Water 1.2MPa Screwed Bronze Screwed, bronze
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SW-10
    SW-10    		 20A -100A
    (3/4"-4")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron or stainless steel Duplex type
    Model Nominal size Application Max. pressure End connection Body Material Feature
    SW-10S
    SW-10S    		 20A -100A
    (3/4"-4")    		 Water
    Oil    		 1MPa JIS flange_JIS 10K Ductile cast iron or stainless steel Duplex type, easy maintenance
    Model Nominal size Application Max. pressure End connection Body Material Feature
    ST-1-10
    ST-1-10    		 25A -300A
    (1"-12")    		 Steam
    Water
    Air,non-dangerous fluids    		 1MPa JIS flange_JIS 10K Stainless steel Temporary strainer
