Pressure Reducing Valve/Drain Separator

Pressure Reducing Valves

Price: Contact

  • Model:

    •

  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Pressure Reducing Valves

    GP-1000HEN, GP-1001, GP-1002, GP-1010, GP-1010S, GP-1000S, GP-1000SS, GP-1000AS, GP-1200, GP-1210, GP-1200S, GP-1210S, GP-1200SS, GP-1000T, GP-1010T, GP-1000TS, GP-1010TS, GP-1200T, GP-1210TS, GP-1000TSS, GP-1000TAS, ​GP-1200TSS, GP-2000CS, GDK-2000, GPK-2001, GPK-2003, CP-2001, CP-2002, CP-2003, CP-2004, CP-2005, GD-200H, GD-200C, GD-200C-N, GD-20, GD-26-NE, GD-27-NE, GD-28-NE, GD-29-NE, GD-27F-N, GD-27BP, GD-26S, GD-27S, GD-28S, GD-29S, GD-26S-NE, GD-27S-NE, GD-28S-NE, GD-29S-NE, GD-41, GD-43-10, GD-43-20, GD-41N, GD-43N-10, GD-43N-20, GD-41G, GD-43G-10, GD-43G-20, GD-7, GD-7B, GD-6, GD-8N, GD-24GS, GD-24GS-N, GD-26G, GD-27G, GD-26GS, GD-27GS, GD-400, GD-400SS, GD-4, GD-4B, GD-9N, GD-46PP, GD-46LL, GD-46KK, GD-46SP, GD-15, GD-25GJ, GD-25GJ-K, GD-17, GD-55-80, GD-55R-80, GD-56-80, GD-56R-80, GD-91R-80

    DOWNLOAD CATALOG

    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000HEN
    GP-1000HEN    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1.6MPa EN flangeEN PN25 Ductile cast iron

    For steam,

    Max. 1.6MPa,

    EN Standard



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1001
    GP-1001    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa JIS flange_JIS 10K Ductile cast iron

    For steam,

    with handle



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1002
    GP-1002    		 15A -100A
    (1/2"-4")    		 Steam 0.1-0.5MPa JIS flange_JIS 10K Ductile cast iron For steam, low pressure



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1010
    GP-1010    		 15A -50A
    (1/2"-2")    		 Steam 0.1-1MPa Screwed Ductile cast iron For steam, screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1010S
    GP-1010S    		 15A -50A
    (1/2"-2")    		 Steam 0.1-1MPa Screwed Ductile cast iron

    For steam,

    SS piston & cylinder,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000S
    GP-1000S    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa JIS flange_JIS 10K Ductile cast iron

    For steam,

    SS piston & cylinder



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000SS
    GP-1000SS    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa JIS flange_JIS 10K Stainless steel

    For steam,

    SS wetted parts



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000AS
    GP-1000AS    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa JIS flange_JIS 10K Stainless steel For steam, All SS



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1200
    GP-1200    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa JIS flange_JIS 10K Ductile cast iron

    For steam,

    remote control



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1210
    GP-1210    		 15A -50A
    (1/2"-2")    		 Steam 0.1-1MPa Screwed Ductile cast iron

    For steam,

    remote control,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1200S
    GP-1200S    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa JIS flange_JIS 10K Ductile cast iron

    For steam,

    remote control,

    SS piston & cylinder



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1210S
    GP-1210S    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa Screwed Ductile cast iron

    For steam,

    remote control,

    SS piston & cylinder,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1200SS
    GP-1200SS    		 15A -50A
    (1/2"-2")    		 Steam 0.1-1MPa JIS flange_JIS 10K Stainless steel

    For steam,

    remote control,

    SS wetted parts



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000T
    GP-1000T    		 15A -100A
    (1/2"-4")    		 Air,non-dangerous fluids 0.1-1MPa JIS flange_JIS 10K Ductile cast iron

    For air,

    stable control



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1010T
    GP-1010T    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 0.1-1MPa Screwed Ductile cast iron

    For air,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000TS
    GP-1000TS    		 15A -100A
    (1/2"-4")    		 Air,non-dangerous fluids 0.1-1MPa JIS flange_JIS 10K Ductile cast iron

    For air,

    SS trim,

    piston and cylinder



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1010TS
    GP-1010TS    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 0.1-1MPa Screwed Ductile cast iron

    For air,

    screwed,

    SS trim,

    piston and cylinder



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1200T
    GP-1200T    		 15A -100A
    (1/2"-4")    		 Air,non-dangerous fluids 0.1-1MPa JIS flange_JIS 10K Ductile cast iron

    For air,

    screwed,

    remote control



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1210TS
    GP-1210TS    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 0.1-1MPa Screwed Ductile cast iron

    For air,

    screwed,

    remote control,

    SS trim,

    piston and cylinder



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000TSS
    GP-1000TSS    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 0.1-1MPa JIS flange_JIS 10K Stainless steel

    For air,

    SS wetted parts



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1000TAS
    GP-1000TAS    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 0.1-1MPa JIS flange_JIS 10K Stainless steel For air, All SS



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-1200TSS
    GP-1200TSS    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 0.1-1MPa JIS flange_JIS 10K Stainless steel

    For air,

    screwed,

    remote control,

    SS wetted parts



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GP-2000CS
    GP-2000CS    		 15A -100A
    (1/2"-4")    		 Steam 0.1-3MPa Screwed
    JIS flange_JIS 10K
    JIS flange_JIS 20K
    JIS flange_JIS 30K
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300
    Socket weld    		 Cast carbon steel

    For steam,

    high pressure,

    large capacity



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GDK-2000
    GDK-2000    		 15A -100A
    (1/2"-4")    		 Steam 0.1-2MPa Screwed
    JIS flange_JIS 10K
    JIS flange_JIS 20K
    EN flangeEN PN25
    ASME flange_ASME Class 150
    ASME flange_ASME Class 300    		 Ductile cast iron

    For steam,

    remote control,

    direct acting



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GPK-2001
    GPK-2001    		 15A -100A
    (1/2"-4")    		 Steam 0.1-2MPa Screwed
    JIS flange_JIS 10K
    JIS flange_JIS 20K    		 Ductile cast iron

    For steam,

    remote control



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GPK-2003
    GPK-2003    		 15A -100A
    (1/2"-4")    		 Steam 0.25-2MPa Screwed
    JIS flange_JIS 10K
    JIS flange_JIS 20K    		 Ductile cast iron

    For steam,

    remote control



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    CP-2001
    CP-2001    		 15A -100A
    (1/2"-4")    		 Steam 0.1-2MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Pressure reducing valve

    with ON/OFF control



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    CP-2002
    CP-2002    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Pressure reducing

    and fully opening valve



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    CP-2003
    CP-2003    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Two switchable

    reduced pressures



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    CP-2004
    CP-2004    		 15A -100A
    (1/2"-4")    		 Steam 0.1-1MPa Screwed
    JIS flange_JIS 10K    		 Ductile cast iron

    Two switchable

    reduced pressures

    and ON-OFF control



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    CP-2005
    CP-2005    		 15A -100A
    (1/2"-4")    		 Steam 0.1-2MPa Screwed
    JIS flange_JIS 10K
    JIS flange_JIS 20K    		 Ductile cast iron

    Pressure and

    temperature

    regulating valve



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-200H
    GD-200H    		 15A -150A
    (1/2"-6")    		 Water
    Oil
    Air,non-dangerous fluids    		 Max.2MPa JIS flange_JIS 20K Ductile cast iron

    For liquid and

    air, Max. 2.0MPa



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-200C
    GD-200C    		 15A -150A
    (1/2"-6")    		 Water
    Oil
    Air,non-dangerous fluids    		 Max.1MPa JIS flange_JIS 10K Ductile cast iron

    For liquid and

    air, nylon 11 coating



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-200C-N
    GD-200C-N    		 15A -150A
    (1/2"-6")    		 Water Max.1MPa JIS flange_JIS 10K Ductile cast iron

    For water,

    nylon 11 coating



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-20
    GD-20    		 15A -100A
    (1/2"-4")    		 Water
    Oil
    Air,non-dangerous fluids    		 Max.1MPa JIS flange_JIS 10K Stainless steel

    For liquid and air,

    stainless steel



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-26-NE
    GD-26-NE    		 15A -50A
    (1/2"-2")    		 Water Max.1MPa Screwed Bronze

    For water,

    JWWA approval



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-27-NE
    GD-27-NE    		 25A -100A
    (1"-4")    		 Water Max.1MPa JIS flange_JIS 10K Bronze

    For water,

    JWWA approval,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-28-NE
    GD-28-NE    		 15A -50A
    (1/2"-2")    		 Water Max.1.6MPa Screwed Bronze

    For water,

    JWWA apprval,

    Max. 1.6MPa



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-29-NE
    GD-29-NE    		 25A -100A
    (1"-4")    		 Water Max.1.6MPa JIS flange_JIS 16K Bronze

    For water,

    JWWA approval,

    Max. 1.6MPa,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-27F-N
    GD-27F-N    		 125A -150A
    (5"-6")    		 Water Max.1MPa JIS flange_JIS 10K Bronze

    For water,

    JWWA approval,

    large size



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-27BP
    GD-27BP    		 20A -100A
    (3/4"-4")    		 Water Max.1MPa JIS flange_JIS 10K Bronze

    For water,

    JWWA approval,

    with by-pass function



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-26S
    GD-26S    		 20A -50A
    (3/4"-2")    		 Water Max.1MPa Screwed Stainless steel

    For water,

    SS wetted parts



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-27S
    GD-27S    		 20A -100A
    (3/4"-4")    		 Water Max.1MPa JIS flange_JIS 10K Stainless steel

    For water,

    stainless steel,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-28S
    GD-28S    		 20A -50A
    (3/4"-2")    		 Water Max.1.6MPa Screwed Stainless steel

    For water,

    stainless steel,

    Max. 1.6MPa



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-29S
    GD-29S    		 20A -100A
    (3/4"-4")    		 Water Max.1.6MPa JIS flange_JIS 16K Stainless steel

    For water,

    stainless steel,

    Max. 1.6MPa,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-26S-NE
    GD-26S-NE    		 20A -50A
    (3/4"-2")    		 Water 1MPa Screwed Stainless steel

    For water,

    SS wetted parts,

    JWWA approval



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-27S-NE
    GD-27S-NE    		 20A -100A
    (3/4"-4")    		 Water 1MPa JIS flange_JIS 10K Stainless steel

    For water,

    stainless steel,

    flanged,

    JWWA approval



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-28S-NE
    GD-28S-NE    		 20A -50A
    (3/4"-2")    		 Water Max.2MPa Screwed Stainless steel

    For water,

    stainless steel,

    Max. 2.0MPa,

    JWWA approved



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-29S-NE
    GD-29S-NE    		 20A -100A
    (3/4"-4")    		 Water Max.2MPa JIS flange_JIS 20K Stainless steel

    For water,

    stainless steel,

    Max. 2.0MPa,

    JWWA approved,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-41
    GD-41    		 15A -25A
    (1/2"-1")    		 Water Max.0.07-2MPa Screwed Stainless steel (SCS14A)

    For water,

    stainless steel,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-43-10
    GD-43-10    		 15A -25A
    (1/2"-1")    		 Water Max.1MPa JIS flange_JIS 10K Stainless steel (SCS14A)

    For water,

    stainless steel,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-43-20
    GD-43-20    		 15A -25A
    (1/2"-1")    		 Water Max.2MPa JIS flange_JIS 20K Stainless steel (SCS14A)

    For water,

    stainless steel,

    flanged,

    Max. 2.0MPa



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-41N
    GD-41N    		 15A -25A
    (1/2"-1")    		 Water Max.0.07-2MPa Screwed Stainless steel (SCS14A)

    For water,

    stainless steel,

    JWWA approval



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-43N-10
    GD-43N-10    		 15A -25A
    (1/2"-1")    		 Water Max.0.07-1MPa JIS flange_JIS 10K Stainless steel (SCS14A)

    For water,

    stainless steel,

    flanged,

    JWWA approval



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-43N-20
    GD-43N-20    		 15A -25A
    (1/2"-1")    		 Water Max.0.07-2MPa JIS flange_JIS 20K Stainless steel (SCS14A)

    For water,

    stainless steel,

    flanged,

    Max. 2.0MPa,

    JWWA approval



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-41G
    GD-41G    		 15A -25A
    (1/2"-1")    		 Air,non-dangerous fluids Max.2MPa Screwed Stainless steel (SCS14A)

    For air,

    stainless steel,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-43G-10
    GD-43G-10    		 15A -25A
    (1/2"-1")    		 Air,non-dangerous fluids Max.1MPa JIS flange_JIS 10K Stainless steel (SCS14A)

    For air,

    stainless steel,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-43G-20
    GD-43G-20    		 15A -25A
    (1/2"-1")    		 Air,non-dangerous fluids Max.2MPa JIS flange_JIS 20K Stainless steel (SCS14A)

    For air,

    stainless steel,

    flanged,

    Max. 2.0MPa



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-7
    GD-7    		 20A -150A
    (3/4"-6")    		 Water
    Oil    		 0.1-1MPa JIS flange_JIS 10K Cast iron

    For liquid,

    double-seated



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-7B
    GD-7B    		 20A -150A
    (3/4"-6")    		 Water
    Oil    		 0.1-1MPa JIS flange_JIS 10K Cast iron

    For liquid,

    double-seated,

    pressure balance

    structure



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-6
    GD-6    		 10A -25A
    (3/8"-1")    		 Water
    Oil
    Air,non-dangerous fluids    		 Max.1MPa Screwed Ductile cast iron

    For liquid and air,

    small flow rate



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-8N
    GD-8N    		 6A -15A
    (1/8"-1/2")    		 Water
    Air,non-dangerous fluids    		 0.1-1MPa Screwed Stainless steel

    316 Stainless steel,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-24GS
    GD-24GS    		 15A -50A
    (1/2"-2")    		 Water 0.2-1.6MPa Screwed Bronze

    For water,

    w/gauge and strainer



    Model Nominal size Application Inlet pressure End connection Body Material Feature

    GD-24GS-N


    GD-24GS-N

    		 15A -50A
    (1/2"-2")    		 Water 0.2-1MPa Screwed Bronze

    For water,

    Max. 1.0MPa,

    w/strainer and gauge,

    JWWA approval



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-26G
    GD-26G    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids Max.1MPa Screwed Bronze

    For air,

    bronze,

    screwed



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-27G
    GD-27G    		 25A -100A
    (1"-4")    		 Air,non-dangerous fluids Max.1MPa JIS flange_JIS 10K Bronze

    For air,

    bronze,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-26GS
    GD-26GS    		 20A -50A
    (3/4"-2")    		 Air,non-dangerous fluids Max.1MPa Screwed Stainless steel

    For air,

    stainless steel



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-27GS
    GD-27GS    		 20A -100A
    (3/4"-4")    		 Air,non-dangerous fluids Max.1MPa JIS flange_JIS 10K Stainless steel

    For air,

    stainless steel,

    flanged



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-400
    GD-400    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 2.5-400kPa JIS flange_JIS 10K Cast iron

    For air,

    reduction ratio 400:1



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-400SS
    GD-400SS    		 15A -50A
    (1/2"-2")    		 Air,non-dangerous fluids 2.5-400kPa JIS flange_JIS 10K Stainless steel

    For air,

    reduction ratio 400:1,

    SS wetted parts



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-4
    GD-4    		 15A -150A
    (1/2"-6")    		 Air,non-dangerous fluids Max.300kPa JIS flange_JIS 20K Cast iron

    For air,

    slight pressure



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-4B
    GD-4B    		 15A -150A
    (1/2"-6")    		 Air,non-dangerous fluids Max.800kPa JIS flange_JIS 10K Cast iron

    For air,

    slight pressure,

    reduction ratio 20:1



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-9N
    GD-9N    		 8A -25A
    (1/4"-1")    		 Air,non-dangerous fluids 0.1-1MPa Screwed Aluminum die cast

    For air,

    aluminium die cast



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-46PP
    GD-46PP    		 20A
    (3/4")    		 Water Max.1MPa Screwed Bronze

    For buildings,

    JWWA approved



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-46LL
    GD-46LL    		 20A
    (3/4")    		 Water Max.1MPa Screwed Bronze

    For buildings,

    JWWA approved



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-46KK
    GD-46KK    		 20A
    (3/4")    		 Water Max.1MPa Screwed Bronze

    For buildings,

    JWWA approved



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-46SP
    GD-46SP    		 20A
    (3/4")    		 Water Max.1MPa Screwed Bronze

    For buildings,

    JWWA approved,

    with stop valve



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-15
    GD-15    		 15A -20A
    (1/2"-3/4")    		 Water 0.1-1MPa Screwed Bronze

    For indivinual water supply,

    JWWA approved



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-15C
    GD-15C    		 15A -20A
    (1/2"-3/4")    		 Water 0.1-1MPa Screwed Bronze

    For indivinual water supply,

    JWWA approved,

    check valve



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-25GJ
    GD-25GJ    		 25A
    (1")    		 Water Max.1MPa Screwed Bronze

    For indivinual water supply,

    JWWA approved



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-25GJ-K
    GD-25GJ-K    		 25A
    (1")    		 Water Max.1MPa Screwed Bronze

    For indivinual water supply,

    JWWA approved



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-17
    GD-17    		 15A -25A
    (1/2"-1")    		 Water Max.1MPa Screwed Bronze

    For water,

    JWWA approved,

    with test gag



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-55-80
    GD-55-80    		 20A
    (3/4")    		 Water 0.1-0.75MPa Screwed Bronze

    JIS approved,

    L=90mm



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-55R-80
    GD-55R-80    		 20A
    (3/4")    		 Water 0.1-0.75MPa Screwed Bronze

    JIS approved,

    L=90mm,

    for cold regions



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-56-80
    GD-56-80    		 20A
    (3/4")    		 Water 0.1-0.75MPa Screwed Bronze

    JIS approved,

    L=115 mm



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-56R-80
    GD-56R-80    		 20A
    (3/4")    		 Water 0.1-0.75MPa Screwed Bronze

    JIS approved, L=115 mm,

    for cold regions



    Model Nominal size Application Inlet pressure End connection Body Material Feature
    GD-91R-80
    GD-91R-80    		 20A
    (3/4")    		 Water 0.1-0.75MPa Screwed Bronze

    JIS approved,

    L=115 mm,

    for cold regions

    Related projects

    Category
    Online support
  • Consulting - Quotation
    Consulting - Quotation
    0902720814
  • Consulting-Technical
    Consulting-Technical
    0907450506
  • Consulting - Quotation
    Consulting - Quotation
    0902601875
  • Consulting - Technical
    Consulting - Technical
    0902800728
  • Consulting - Quotation
    Consulting - Quotation
    0979737351
    • Featured products

    Sign up to receive news, new events from us

      Social network









    Copyright © 20017 Copyright by Phuc Minh Technology Co., Ltd
