Pressure Reducing Valve/Drain Separator

GD-45P - Pressure Reducing Valves for Steam

Price: Contact

Model: GD-45P

DOWNLOAD CATALOG

Trademark: YOSHITAKE

Origin: Japan

Order

Project details Download Catalogue Evaluate

Pressure Reducing Valves for Steam

GD-45P

* Inlet: Max. 2.0 MPa
* Small and compact
* Superior performance and durability
* Easy installation and operation with handle
* Integral strainer prevents dirt problem

Specifications

Features		For steam, Max. 2.0MPa, with handle
Type		Direct-acting type
Specifications	Product type	Direct-acting type
	Nominal size	15A (1/2") - 25A (1")
	Application	Steam
	End connection	JIS Rc or NPT screwed
	Inlet pressure	Max. 2 MPa
	Reduced pressure	0.02 - 1 MPa (*)
	Min. differential pressure	0.05 MPa
	Max. pressure reduction ratio	10 : 1
	Working temperature	Max. 220 degree(C)
	Valve seat leakage	0.1% or less of rated flow
Material	Body	Ductile cast iron
	Valve & seat	Stainless steel
	Spindle	Stainless steel
	Bellows	Bronze
	Handle	Plastic
