Pressure Reducing Valve/Drain Separator

GD-200 - Pressure Reducing Valves for liquid and air

Price: Contact

  • Model: GD-200

    • DOWNLOAD CATALOG

  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Pressure Reducing Valve for liquid and air

    GD-200

    * Stable reduced pressure against fluctuation of inlet pressure because of pressure balance mechanism

    Specifications

    Features For liquid and air, Max. 1.0MPa
    Type Direct-acting type
    Specifications Product type Direct-acting type
    Nominal size 15A (1/2") - 150A (6")
    Application Water, oil (kerosene,heavy oil A and B), air, other non-dangerous fluids
    End connection JIS 10K FF flanged, ASME Class 150 flanged
    Inlet pressure Max. 1 MPa
    Reduced pressure 0.05 - 0.7 MPa (*)
    Max. temperature 80 degree(C)
    Min. differential pressure 0.05 MPa
    Max. pressure reduction ratio 10 : 1
    Working temperature 5 - 80 degree(C)
    Material Body Ductile cast iron
    Valve NBR
    Valve seat Stainless steel
    Diaphragm NBR

    Remarks

    * Reduced pressure
    A: 0.05-0.25 MPa
    B: 0.26-0.7 MPa

    Dimensions and Weights
    Size L (mm) H (mm) Weight (kg) Cv value
    15A(1/2) 145 310 8.2 2.5
    20A(3/4) 150 310 8.2 4
    25A(1) 150 333 10.0 5
    32A(1-1/4) 195 397 17.3 8
    40A(1-1/2) 195 397 17.3 12
    50A(2) 195 415 19.2 16
    65A(2-1/2) 270 555 40.0 28
    80A(3) 270 582 43.7 36
    100A(4) 308 645 70.7 68
    125A(5) 380 849 144.0 75
    150A(6) 400 918 173.0 108
