Safety valve Model 64LC, 64GC, 64GF, 64LF.

Safety valve 90º angular type of rapid opening (pop action), full nozzle, and spring loaded, adjusting ring, conventional or balanced.

Design:

EN ISO 4126-1 | ASME VIII | API-526 | ASME B16.34

Sizes:

from 1” x 2” up to 12” x 16”

Flanges  rating:

Inlet 150 ÷ 2500#

Outlet 150 ÷ 300#

Also supplied with DIN flanges.

Materials:

Carbon steel, stainless steel and special alloys.

(Hastelloy, Inconel, Duplex, Super duplex, etc.)

Available models:

64LC, 64GC, 64GF, 64LF.

• Documents

PDF - 0.52 Mb

MOD.64 ATEX 2014/34UE

PDF - 1.81 Mb

Catalogue Mod 64 ENG

PDF - 0.15 Mb

Certificate of quality system approval - Models 3-5111; 3-5161; 3-5000;5100; 5500; 6400 ; MVP648T10

PDF - 1.85 Mb

Certificate EAC VN TR CU 012 ATEX - Models 3-50;3-51; 5500; 6400

PDF - 1.17 Mb

Certificate EAC VN TR CU 032 (PED) - Models 6400, 5500, 3-51, 3-50

PDF - 0.24 Mb

Certificate EAC VN TR CU 010 - Models 6400, 3-5500, 3-51, 3-50

PDF - 0.18 Mb

Certificate of authorization ASME UV

PDF - 0.35 Mb

Certificate of authorization NB UV - Models 6400 and 5100

PDF - 0.76 Mb

EC Type-examination certificate - Model 6400

PDF - 0.28 Mb

Declaration of conformity potentially explosive atmospheres - ATEX - Model 6400
