Pressure Reducing Valve/Drain Separator

GD-6N - Pressure Reducing Valve for Steam

Price: Contact

  • Model: GD-6N

    • DOWNLOAD CATALOG

  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Pressure Reducing Valve for Steam

    GD-6N

    * Easy installation and operation
    * Integral strainer prevents dirt problem

    Specifications

    Features For steam, small flow rate
    Type Direct-acting type
    Specifications Product type Direct-acting type
    Nominal size 10A (3/8") - 25A (1")
    Application Steam
    End connection JIS Rc screwed
    Inlet pressure Max. 1 MPa
    Reduced pressure 0.02 - 0.4 MPa (*)
    Min. differential pressure 0.05 MPa
    Max. pressure reduction ratio 10 : 1
    Working temperature Max. 220 degree(C)
    Material Body Ductile cast iron
    Valve & seat Stainless steel
    Spindle Stainless steel
    Diaphragm Stainless steel

    Remarks

    * Reduced pressure
    A: 0.02-0.1 MPa
    B: 0.1-0.4 MPa

    Dimensions and Weights
    Size L (mm) H (mm) Weight (kg) Cv value
    10A(3/8) 165 243 5.5 0.35
    15A(1/2) 165 243 5.5 0.5
    20A(3/4) 185 267 8.2 1
    25A(1) 185 267 8.2 1.5
