Pressure Reducing Valve/Drain Separator

GD-45- Pressure Reducing Valves for Steam

Price: Contact

  • Model: GD-45
  •

  • Trademark: YOSHITAKE
  • Origin: Japan
  • Pressure Reducing Valves for Steam

    GD-45

    DOWNLOAD CATALOG

    * Inlet: Max. 2.0 MPa
    * Small and compact
    * Superior performance and durability
    * Easy installation and operation
    * Integral strainer prevents dirt problem

    Specifications



    Features For steam, Max. 2.0MPa
    Type Direct-acting type
    Specifications Product type Direct-acting type
    Nominal size 15A (1/2") - 25A (1")
    Application Steam
    End connection JIS Rc or NPT screwed
    Inlet pressure Max. 2 MPa
    Reduced pressure 0.02 - 1 MPa (*)
    Min. differential pressure 0.05 MPa
    Max. pressure reduction ratio 10 : 1
    Working temperature Max. 220 degree(C)
    Valve seat leakage 0.1% or less of rated flow
    Material Body Ductile cast iron
    Valve & seat Stainless steel
    Spindle Stainless steel
    Bellows Bronze

    Remarks

    * Reduced pressure
    A: 0.02-0.1 MPa
    B: 0.05-0.4 MPa
    C: 0.35-1.0 MPa


    Dimensions and Weights
    Size L (mm) H (mm) Weight (kg)
    15A(1/2) 111 216 3.2
    20A(3/4) 111 216 3.2
    25A(1) 111 216 3.2
