Pressure Reducing Valve/Drain Separator

GP-1000EN - Pressure Reducing Valves for Steam

Price: Contact

  • Model: GP-1000EN

    • DOWNLOAD CATALOG

  • Trademark: YOSHITAKE
  • Origin: Japan
    • Project details Download Catalogue Evaluate

    Pressure Reducing Valves for Steam

    GP-1000EN

    * Face-to-face dimensions of the EN standard
    * Superior durability
    * Stable performance
    * Valve leakage meets ANSI Class IV
    * High reduction ratio (20:1)

    Specifications

    Features For steam, EN Standard
    Type Pilot operated piston type
    Specifications Product type Pilot-operated type
    Nominal size 15A (1/2") - 100A (4")
    Application Steam
    End connection EN PN16 flanged
    Inlet pressure 0.1 - 1 MPa
    Reduced pressure 0.05 - 0.9 MPa
    Reduced pressure 90% or less of the inlet pressure(gauge pressure)
    Min. differential pressure 0.05 MPa
    Max. pressure reduction ratio 20 : 1
    Working temperature Max. 220 degree(C)
    Valve seat leakage 0.01% or less of rated flow
    Material Body Ductile cast iron
    Valve and valve seat Stainless steel
    Piston, cylinder Brass and Bronze
    Diaphragm Stainless steel
