Pressure Reducing Valve/Drain Separator
Price: Contact
Pressure Reducing Valve for Water
GD-24
* Small and compact
* Superior performance and durability
* Easy installation and operation
Specifications
| Features | For water, Max. 1.6 MPa, screwed | |
|---|---|---|
| Type | Direct-acting type | |
| Specifications | Product type | Direct-acting type |
| Nominal size | 15A (1/2") - 50A (2") | |
| Application | Water | |
| End connection | JIS Rc screwed | |
| Inlet pressure | 0.2 - 1.6 MPa | |
| Reduced pressure | 0.5 - 0.55 MPa | |
| Min. differential pressure | 0.05 MPa | |
| Max. pressure reduction ratio | 10 : 1 | |
| Working temperature | 5 - 80 degree(C)* | |
| Material | Body | Bronze |
| Valve | Urethane Rubber | |
| Valve seat | Stainless steel | |
| Diaphragm | NBR | |
Remarks
*Do not use the valve continuously at a temperature of 70 degree(C) or above.
Dimensions and Weights
| Size | L (mm) | H (mm) | Weight (kg) | Cv value |
|---|---|---|---|---|
| 15A(1/2) | 80 | 193 | 1.8 | 1.5 |
| 20A(3/4) | 90 | 210 | 2.4 | 1.9 |
| 25A(1) | 100 | 230 | 3.3 | 3 |
| 32A(1 1/4) | 120 | 265 | 4.7 | 4 |
| 40A(1 1/2) | 150 | 315 | 8.2 | 7 |
| 50A(2) | 185 | 365 | 14.3 | 10 |
