Pressure Reducing Valve for Steam
GD-30S
* Wetted Parts: Stainless steel
* Small, compact and advanced design
* Superior performance and durability
* Easy adjustment with handle
* Integral strainer prevents dirt problem
Specifications
| Features | For steam, SS wetted parts | |
|---|---|---|
| Type | Direct-acting type | |
| Specifications | Product type | Direct-acting type |
| Nominal size | 15A (1/2") - 25A (1") | |
| Application | Steam | |
| End connection | JIS Rc or NPT screwed | |
| Inlet pressure | Max. 2 MPa | |
| Reduced pressure | 0.02 - 1 MPa (*) | |
| Max. temperature | 220 degree(C) | |
| Min. differential pressure | 0.05 MPa | |
| Max. pressure reduction ratio | 10 : 1 | |
| Working temperature | Max. 220 degree(C) | |
| Valve seat leakage | 0.1% or less of rated flow | |
| Material | Body | Stainless steel |
| Valve & seat | Stainless steel | |
| Bellows | Stainless steel | |
Remarks
* Reduced pressure
A: 0.02-0.1 MPa
B: 0.05-0.4 MPa
C: 0.35-1.0 MPa
Dimensions and Weights
| Size | L (mm) | H (mm) | Weight (kg) |
|---|---|---|---|
| 15A(1/2) | 80 | 196 | 1.9 |
| 20A(3/4) | 85 | 196 | 1.9 |
| 25A(1) | 95 | 196 | 2.0 |
