Steam Trap

TKK 41 Steam Trap Screwed

Price: Contact

  • Model: TKK 41
  • Trademark: SAMYANG
  • TKK 41 Steam Trap Screwed

    TKK 41 is ideal for high corrosive environment or where ammonia is discharged. TKK 41
    Steam trap has been designed to be suitable for high corrosive environment. Like any other
    steam traps TKK 41has been produced in accordance to German Regulation of Boiler (TRD)
    / Pressure Vessel (AD) and DIN standard of design and tests. Steam trap with membrane
    capsule adjusting device can resist on corrosion and does not get effected by water hammer.
    TKK 41 Steam Trap includes flat strainer with body made only by stainless steel with low
    discharge capacity. TKK41 is impossible to maintain and repair. TKK 41 is suitable for medicine
    or food industry. Steam trap contains standard membrane capsules.

    Specification:

    • Type: TKK 41
    • Size: 15 (1/5 “) ~ 25 (1”)
    • Maximum permissible pressure: 55bar
    • Maximum operational pressure: 45bar
    • Maximum applied temperature: 250℃
    • Differential pressure: 21bar
    • Connection: screwed NPT acc. to ANSI B1 20.1 or BSP acc. to BS 21
    • Material:
      • Body: STS
      • Disc, Seat: STS

    ▶ Install a strainer (80 MESH or more) at the front end when installing the valve.
