TDK 45 Disc Steam Trap Screwed

Like any other steam traps TDK 45 has been produced in accordance to German Regulation of Boiler (TRD) / Pressure Vessel (AD) and DIN standard of design and tests.
Opposite pressure will not exceed 80% of front pressure. Internal parts are made of stainless steel and body is made of forged steel. Strainer is easy to clean and maintain
as it’s a Y-type located in lower part of body

Specification:

• Type: TDK 45
• Size: 15(1/5“)~25(1")
• Applicable fluid: Condensate
• Maximum permissible pressure : 65bar
• Maximum operational pressure : 40 bar
• Maximum applied temperature : 400℃
• Differential pressure : 32bar
• Connection : screwed or socket weld
  • Screwed: NPT acc. to ANSI B1 20.1 / BSP acc. to BS 21
  • Socket Weld: ANSI B 16.11
• Material:
  • Body: STS
  • Disc, Seat: STS

▶ Install a strainer (80 MESH or more) at the front end when installing the valve.
