TKK 2Y Steam Trap Screwed

Like any other steam traps TDK 2Y has been produced in accordance to German
Regulation of Boiler (TRD) / Pressure Vessel (AD) and DIN standard of design and tests.
Steam trap with membrane capsule adjusting device can resist on corrosion and does
not get effected by water hammer. TKK 2Y Steam Trap includes strainer. This type
of steam trap can be operational in any locations and includes standard membrane
capsule. Specially designed seat interior stainless steel ball can be operated as check
valve.

Specification:

• Type: TKK 2Y
• Size: 15 (1/5 “) ~ 25 (1”)
• Maximum permissible pressure: 40bar
• Maximum operational pressure: 32bar
• Maximum applied temperature: 250℃
• Differential pressure: 22bar
• Connection: screwed, socket weld
  • Screwed: NPT acc. to ANSI B1 20.1 or BSP acc. to BS 21
  • Socket Weld: ANSI B 16.11
• Material:
  • Body: STS
  • Disc, Seat: STS

▶ Install a strainer (80 MESH or more) at the front end when installing the valve.
