YAF-14S Ball Float Steam Trap Screwed

This is a lever float type steam trap that can be used where pressure is high and where
a large volume of condensate is generated, such as heat exchangers, room heating and
water heating facilities, and air-conditioning and heating facilities


Features

• Outstanding performance in continuous discharge, regardless of load fluctuations of condensate.
• Built-in automatic Air Vent ensuring no air binding.
• Easy repair and inspections : simply remove the cover for repair and inspections. The float assembly is attached to the cover

Specification:

• Type: YAF-14S
• Size: 15(1/2“)~50(2")
• Applicable fluid: Condensate
• Applicable pressure range: 0.44, 1.0, 1.4MPa
• Applicable temperature: 220°C below
• Material:
  • Body: GCD450
  • Seat: STS
  • Float, Lever: STS
• End connection: KS PT SCREW
• Hydraulic test pressure: 1.5 times of applicable flange rating

▶ Install a strainer (40 MESH or more) at the front end when installing the valve.
