TDK PS Steam Trap Screwed

TDK PS Steam Trap internal parts are made of stainless steel and body is made of
stainless casting. In every condition the maximum back pressure will not exceed 80%
of inlet pressure. If not the trap will not function properly. TDK 71 simply discharges in
relation to condensate level. All parts have spare parts so its easy to maintain. Strainer
is easy to clean and maintain as it’s a Y-type located in lower part of body. It can
be installed in both horizontally and vertically; however, it is recommended to install in
horizontal pipelines.

Specification:

• Type: TDK PS
• Size: 15 (1/5 “) ~ 25 (1”)
• Maximum permissible pressure: 63bar
• Maximum operational pressure: 42bar
• Maximum applied temperature: 400℃
• Connection: Screwed NPT acc. to ANSI B1 20.1 / BSP acc. to BS 21
• Material:
  • Body: STS
  • Disc, Seat: STS

▶ Install a strainer (80 MESH or more) at the front end when installing the valve.
