Steam Trap

YRS-3 Type Radiator Trap Screwed

Price: Contact

  • Model: YRS-3
  • Trademark: SAMYANG
  • YRS-3 Type Radiator Trap Screwed

    This is a thermo-wax type radiator trap that is used for heating radiators

    Features

    • No concern about freezing damages : no condensate remaining in the trap.
    • No steam leakage : discharging condensate only when it is 100°C or below.
    • Quickly discharging condensate and air.
    • Compact & strong : The product can be used almost permanently. If needed, just replace the element.
    • Distance among surfaces and the union nipple part - Same regulations on heating radiator traps KS B 6403 are applied

    Specification:

    • Type: YRS-3
    • Size: 15 (1/5 “) ~ 20 (3/4”)
    • Applicable pressure: 0.01~0.15MPa => Fluid temperature: 100℃ below
    • Applicable pressure: 0.15~0.3MPa = > Fluid temperature: 150℃ below
    • Connection: KS PT SCREW (Union nipple)
    • Material:
      • Body: C3771
      • Disc, Seat: STS
    • Hydraulic test pressure: 1.5 times of applicable flange rating
