Steam Trap
TDK 71 Thermodynamic Steam Trap Screwed
TDK 71 Steam Trap internal parts are made of stainless steel and body is made of
stainless casting. In every condition the maximum back pressure will not exceed 80%
of inlet pressure. If not the trap will not function properly. TDK 71 simply discharges in
relation to condensate level. Strainer is easy to clean as it a Y-type located in lower part
of body. It can be installed in both horizontally and vertically; however, it is recommended
to install in horizontal pipelines.
Specification:
- Type: TDK 71
- Size: 15(1/5“)~25(1")
- Applicable fluid: Condensate
- Maximum permissible pressure: 63 bar
- Maximum operational pressure: 42 bar
- Maximum applied temperature: 400℃
- Material:
- Body: STS
- Disc, Seat: STS
- End connection: screwed NPT acc. to ANSI B1 20.1 / BSP acc. to BS 21
▶ Install a strainer (80 MESH or more) at the front end when installing the valve.
