Steam Trap

TKK 3 Steam Trap Screwed

Price: Contact

  • Model: TKK 3
  • Trademark: SAMYANG
  • TKK 3 Steam Trap Screwed

    TKK 3 is specially designed to fit where there is high condensate discharge level and
    high water hammer resistance. Like any other steam traps TKK 43 has been produced
    in accordance to German Regulation of Boiler (TRD) / Pressure Vessel (AD) and DIN
    standard of design and tests. Steam trap with membrane capsule adjusting device can
    resist on corrosion and does not get effected by water hammer. The difference between
    other steam trap and TKK 3 Steam trap is that it contains flat strainer and 3 thermostatic
    capsules. This type of steam trap operates in any locations and includes standard “S”
    type membrane capsules.

    Specification:

    • Type: TKK 3
    • Size: 15 (1/5 “) ~ 25 (1”)
    • Maximum permissible pressure: 40bar
    • Maximum operational pressure: 32bar
    • Maximum applied temperature  250℃
    • Differential pressure: 22bar
    • Connection: screwed, socket weld
      • Screwed: NPT acc. to ANSI B1 20.1 or BSP acc. to BS 21
      • Socket Weld: ANSI B 16.11
    • Material:
      • Body: STS
      • Disc, Seat: STS

    ▶ Strainer (over 80 Mesh) installation is required to ahead inlet when installing valve
