SWISSFLUID Valves

SST - Sight Glasses

Price: Contact

  • Model: SST
  •

    Download Brochures

    pdf Process Valves and Automation



  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Sight Glasses SST Swissfluid

    Sight Glasses fully made of stainless steel as reliable flow indicators for process media in either liquid or even gaseous state.


    Main features

    • Heavy-duty, proven construction - maintenance-free
    • Horizontal or vertical installation
    • For liquids, gases and steam
    • Large observation opening
    • Standard drip ledge indicating even lowest flow



    Technical data

    Version DIN / ISO ANSI
    Sizes DN15 – DN150 ½" – 6"
    Flanges

    DIN EN 1092-1 B1
    PN16
    ASME B16.5 RF
    ANSI 150lbs
    Buttwelding ends DIN EN 12982 -
    Face to face EN 558-1 series 1 ASME B16.10
    Body/cover Stainless steel casting 1.4408 AISI 316 CF-8M
    Buttwelding ends Stainless steel casting 1.4404 AISI 316L CF-3M
    Glass plates Borosilicate 8488 acc. to DIN 7080
    Gasket (primary) PTFE-T
    Gasket (outer) C-4400 asbestos-free
    Operating conditions (depending on material selection)
    Pressure 1mbar up to 16 bar (40 bar)
    Temperature -40°C up to +200°C (-40°F up to +392°F)




    Options

    Pressure rating PN40, ANSI 300lbs
    Flanges with groove acc. to DIN 2512 Form N
    Glass Quartz glass, metal-reinforced glasses
    Glass protection FEP-foil
    Flow indication visual indication for gases (PTFE ribbon, rotor)
