SBV - Fully lined Ball Valves Swissfluid

Price: Contact

  • Model: SBV
  •

  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Fully lined Ball Valves SBV Swissfluid

    Fully lined Ball Valves for shut-off and control of corrosive, permeating liquids or gaseous media.


    Main features

    • Two-piece body, metal-to-metal joint
    • Anchored lining with positive locking to body
    • Dynamic, maintenance-free shaft sealing acc. to TA-Luft
    • One-piece ball/shaft, blow out proof, core of SS Duplex
    • Rated breaking point outside of valve
    • Bodies with optional flange connections PN40
    • Ball options such as V-port, C-port, with pressure relief hole
    • ISO top flange for direct mounting of pneumatic quarter turn actuators



    Technical data

    Version DIN / ISO ANSI
    Sizes

    DN15 – DN150
    full port
    ½" – 6"
    full port
      DN150 – DN250
    reduced port
    6" – 10"
    reduced port
    Flanges

    EN 1092-1 B1
    PN16 / PN40
    ASME B16.5 RF
    ANSI 150lbs
    Face to face EN 558-1 series 1 ASME B16.10
    Body Cast steel 1.0619 ASTM A216 WCB
    Lining PFA, PFA-AS (conductive)
    Ball PFA, PFA-AS-encapsulated (conductive)
    Operating conditions (depending on material selection)
    Pressure up to 16 bar
    Temperature -40°C up to +200°C




    Options

    Body Stainless steel casting 1.4408 AISI 316 CF-8M
    Lining ETFE
    Ball PVDF, ETFE, SS Duplex solid, Titanium Grade 2, Hastelloy C,
    V-Port, C-Port
    Handlever Padlock
