SWISSFLUID Valves

SBV 300 lbs - Fully lined Ball Valves

Price: Contact

  • Model: SBV 300 lb
  • Ball Valves SBV 300 lbs Swissfluid

    • Status: order
    • Model: SBV 300 lb
  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Ball Valves SBV 300 lbs

    Fully lined Ball Valves for shut-off and control of corrosive, permeating liquids or gaseous media.


    Main features

    • Two-piece body, metal-to-metal joint
    • Anchored lining with positive locking to body
    • Dynamic, maintenance-free shaft sealing acc. to    TA-Luft
    • One-piece ball/shaft, blow out proof, core of SS    Duplex
    • Rated breaking point outside of valve
    • Bodies with optional flange connections PN40 as    well as ANSI Class 150
    • Ball options such as V-port, C-port, with pressure    relief hole
    • ISO top flange for direct mounting of pneum.    quarter turn actuators



    Technical data

    Version ANSI
    Sizes

    1" – 3"
    full port

    Flanges

    ASME B16.5 RF
    ANSI 300lbs

    Face to face ASME B16.10
    Body ASTM A216 WCB
    Lining PFA, PFA-AS (conductive)
    Ball PFA, PFA-AS-encapsulated (conductive)
    Operating conditions (depending on material selection)
    Pressure up to 50 bar
    Temperature -40°C up to +200°C




    Options

    Body Stainless steel casting 1.4408 AISI 316 CF-8M
    Lining ETFE
    Ball PVDF, ETFE, SS Duplex solid, Titanium Grade 2, Hastelloy C,
    V-Port, C-Port
    Handlever Padlock
