SSP-T - Tubular Sight Glasses Swissfluid

Price: Contact

Model: SSP-T

Download Brochures

Process Valves and Automation

Trademark: SWISSFLUID

Origin: Switzerland

Order

Project details Download Catalogue Evaluate

Tubular Sight Glasses SSP-T Swissfluid

Fully lined Tubular Sight Glasse SSP-T as reliable flow indicator for process media in either liquid or gaseous state.

Main features

• 360° circumferential visibility over the entire length
• Cavity-free at horizontal and vertical installation
• Additional safety by PMMA protection tube
• Easy cleaning and maintenance

Technical data

Version	DIN / ISO	ANSI
Sizes	DN15 – DN150	½" – 6"
Flanges	EN 1092-1 B1 PN16	ASME B16.5 ANSI 150lbs
Face to face	EN 558-1 series 1	ASME B16.10
Flanges	1.4404/PFA	AISI 316L/PFA
Tie bars	1.4404	AISI 316L
Lining	PFA
Glass cylinder	Borosilicate 3.3
Safety shield	PMMA-XT (Acrylic glass)
Gaskets	PTFE/FPM insert or PTFE/VMQ
Operating conditions	(depending on material selection)
Pressure	1mbar up to 16 bar
Temperature	-40°C up to +160°C

Options

Flanges	Titanium Grade 2, Hastelloy C
Lining	PFA-AS (conductive), PVDF, PP, ETFE
Gaskets	PTFE-T
Flow indication	visual indication for gases (PTFE ribbon)
Flange connections	PN40, ANSI 150lbs, ANSI 300lbs, JIS 10K
