SWISSFLUID Diapharm Valves

SBC - Ball Check Valves

Price: Contact

Model: SBC

Ball Check Valves SBC Swissfluid

Status: order
Model: SBC

Download Brochures

Process Valves and Automation

Trademark: SWISSFLUID

Origin: Switzerland

Order

Project details Download Catalogue Evaluate

Ball Check Valves SBC

Fully lined Ball Check Valves for safe non-return flow control of corrosive process media. Typical installations are in front of pumps, as overflow protection for liquids and in venting applications.

Main features

• Horizontal or vertical installation
• Large safety glass plates
• Solid or hollow balls
• Quad ball guide
• For liquids, gases and steam
• Bubble tight at low differential pressure

Technical data

Version	DIN / ISO	ANSI
Sizes	DN15 – DN150	½" – 6"
Flanges	EN 1092-1 B1 PN16	ASME B16.5 RF ANSI 150lbs
Face to face	EN 558-1 series 1	ASME B16.10
Body/cover	Cast steel 1.0619	ASTM A216 WCB
Lining	PFA, PFA-AS (conductive)
Solid ball	PTFE, PTFE-AS (conductive)
Glass plates	Borosilicate acc. to DIN 7080
Ball guide	PTFE-R
Gasket (outer)	C-4400 asbestos-free
Operating conditions	(depending on material selection)
Pressure	up to 10 bar
Temperature	-40°C up to +200°C

Options

Body/cover	Stainless steel casting 1.4408	AISI 316 CF-8M
Body	Stainless steel casting 1.4404	AISI 316L CF-3M
Solid ball	PTFE-T, PP, UHMWPE, PTFE-encapsulated
Hollow ball	PTFE, Titanium Grade 2
Safety plate	Stainless steel with PTFE-T instead of glass plates
Glass protection	FEP-foil for HF service (hydrofluoric)
