SWISSFLUID Valves

SSB - Sampling Ball Valves

Price: Contact

  • Model: SSB
  • Sampling Ball Valves SSB Swissfluid

    • Status: order
    • Model: SSB

    Download Brochures

    pdf Process Valves and Automation



  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Sampling Ball Valves SSB

    Sampling Ball Valves fully lined or in stainless steel with full port for safe and defined sampling with no process interruption. Sampling of corrosive media and process media with solids out of pipelines and vessels.


    Main features

    • Body lined or fully made of stainless steel
    • Easy and safe operation, nonpressurized sampling
    • Horizontal or vertical installation
    • Defined sampling volume
    • Extraction of smallest samples
    • Full port design, easy cleaning (piggable)
    • Sampling from vacuum systems
    • Interruption of system pressure through pressure lock
    • Simple automation with time control
    • Sampling unit for installation onto vessels



    Technical data

    Version ANSI
    Sizes ½" – 6"
    Flanges

    ASME B16.5 RF
    ANSI 150 lbs

    Face to face ASME B16.10
    Body Stainless steel casting 1.4408 AISI 316 CF-8M
    Lining PFA, PFA-AS (conductive)
    Ball/Ball seats ETFE/PTA, PFA-AS/PTFE-AS (conductive), SS316/PTFE
    Operating conditions (depending on material selection)
    Pressure 0.01 psi up to 232 psi
    Temperature -40°F up to +300°F (linded), +400°F (unlined)




    Options

    Body Butt weld ends, clamp connection
    Ball/liner PFA/PTFE, stainless steel 1.4404, Hastelloy C, Titanium Grade 2
    Flanges PN40, ANSI 300lbs, JIS 10K, with groove acc. to DIN 2512 Form N
    Additions








    Purge connection
    Lock
    Block flange as per customer specification for installation onto vessels
    Safety cabinet with window glass plates - ESG float glass
    Needle adapter made of stainless steel or Hastelloy C
    Adapter with metal safety basket, incl. spring loaded PP plate
    Bottle support with PP plate, height-adjustable
    Activated carbon filter
    Pneumatic quarter turn actuator for automated sampling
