SWISSFLUID Valves

SDV - Fully lined Diaphragm Valve Swissfluid

Price: Contact

  • Model: SDV
  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Fully lined Diaphragm Valve SDV Swissfluid

    • The key features of the Swissfluid SDV Diaphragm Valve are reliability and simplicity in construction.
    • Its cavity-free and self-draining design make our SDV Diaphragm Valve the preferred choice for chemical and pharmaceutical applications.
    • The simple maintenance and the possibility to replace the diaphragm assembly without having to remove the valve from the line makes this valve also a popular choice in other industries.
    • We offer our SDV Diaphragm Valve in accordance with DIN specification (EN 1092, EN 558-1, cat. 1) as well as ANSI (ASME B16.5, MSS SP-88).
    • The standard configuration consists of a 1.0619 cast steel body (per ASTM A216 WCB), fully lined with PFA and a PTFE/EPDM diaphragm.
    • This economically priced combination affords the highest chemical resistance against virtually all chemicals.
    • Swissfluid also offers this valve in 1.4408 SS (CF-8M; AISI 316) with a choice of liners such as PFA-AS (anti-static), polypropylene or PVDF, and an optional low diffusion, triple-layer diaphragm.
    • Our SDV Diaphragm Valve can be factory-equipped with pneumatic or electric actuators, making it suitable for automatic on-off applications or in connection with positioners for use as control valves.
    • Actuators are available with polypropylene housings (economical, corrosion-proof, light weight) or with sturdy steel enclosures.
