SWISSFLUID Valves

SSC - Swing Check Valves

Price: Contact

  • Model: SSC
  • Swing Check Valves SSC Swissfluid

    • Status: order
    • Model: SSC

    Download Brochures

    pdf Process Valves and Automation



  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Swing Check Valves SSC

    Fully lined Swing Check Valves for safe non-return flow control of corrosive process media.


    Main features

    • Wafer-style body, two- and three-piece, DIN/ANSI combined
    • Centering lugs for safe installation
    • Tilted disc (to shut by gravity even when pipe isn't completely level)
    • Self-retaining disc, no counter flanges needed to hold the disc in place
    • Horizontal or vertical installation
    • Integrated sealing lip (to seal at low differential pressures)



    Technical data

    Version DIN / ISO ANSI
    Sizes DN40 – DN600 1½" – 24"
    Flanges

    EN 1092-1 B1
    PN10/16
    ASME B16.5 RF
    ANSI 150lbs
    Face to face EN 558-1 series 20 ASME B16.10
    Body Cast steel 1.0619 ASTM A216 WCB
    Lining PFA, PFA-AS (conductive)
    Valve disc PFA, PFA-AS-encapsulated (conductive)
    Operating conditions (depending on material selection)
    Pressure up to 10 bar
    Temperature -40°C up to +200°C




    Options

    Body Stainless steel casting 1.4408 AISI 316 CF-8M
    Valve disc SS316L, Titanium Grade 2, Hastelloy C
