SWISSFLUID Valves

SPA-L - Pneumatic Linear Stroke Actuator

Price: Contact

  • Model: SPA-L
  • Pneumatic Linear Stroke Actuator SPA-L Swissfluid

    • Status: order
    • Model: SPA-L

    Download Brochures

    pdf Process Valves and Automation



  • Trademark: SWISSFLUID
  • Origin: Switzerland
  • Pneumatic Linear Stroke Actuator SPA-L

    Compact Pneumatic Linear Stroke Actuators for safe, reliable automation of diaphragm and inline sampling valves. Suitable for installation in most demanding surroundings thanks to corrosion resistant plastic housing.


    Main features

    • Rugged corrosion resistant PP housing
    • For dry or lubricated, filtered air
    • Compact design, directly mounted onto Swissfluid diaphragm valves and inline sampling valves
    • Monitoring connection on stainless steel bracket
    • Easy mounting of control devices
    • Visual position indicator
    • Pre-compressed spring cartridges for safe dismantling



    Technical Data

    Version double acting DA single acting FC/FO
    Air supply filtered air (neutral, not aggressive gas up to 40°C)
    Pressure

    4 bar - max. 5 bar for DA / FO version
    4 bar - max. 7 bar for FC version
    Auxiliary connection NAMUR VDI/VDE 3845 (partly with adapter plate)
    Actuating power 1770 N up to 27570 N (at 5 bar)
    Temperature -10°C up to +80°C




    Options

    Accessories

    Solenoid valves, limit switches, P/P and I/P positioners, stroke limiter (min./max.), manual override, mufflers, throttling valves
    Body Steel, two-component epoxy coated (Bonnet Type)
    Actuating power 1500 N up to 79'000 N (for 6 bar)
    Temperature -40°C up to +80°C
