HERSHEY Plastic Piping and Valves

Diaphargm Valve HERSHEY VP710

Price: Contact

  • Model: VP710
  •

  • Origin: Taiwan
  • Diaphargm Valve HERSHEY VP710

    Materials                           :  UPVC, CPVC, PP, PVDF

    Seal/membrane                :  PTFE/EPDM/FPM

    Stem shaft                        :   C3602, SUS 304, SUS 316

    Standards                        :  ANSI, JIS, DIN

    Size                                 :  1/2"-8" DN15-200

    Working pressure           : 150 PSI  (10 kg/cm2  )

    Connection type             :   Bich connection

    Working temperature     :  0~550C (PVC),  0-800C (PP), 0-900C (CPVC), -20~1200C (PVDF)

    Brand                              :  HERSHEY  Taiwan

    Applications                   :  Pipeline systems for pure water/RO/DI, acid/alkaline chemicals, salt water, drinking water, wastewater...



    Describe:

    -Pressure: 1/2"~3" 150 PSI, 4"~6" 72 PSI, 8" 43 PSI at 230C (Working pressure is variable according to diaphragm material and temperature.)

    -Smooth operation with clear open/close indication through the transparent gauge cover

    -Low maintenance costs with replaceable diaphragm and long service life

    -Adjustable stopper can avoid over-tightening.

    Note:

    -The valve will close completely when the crank can no longer rotate with normal torque, it should not be rotated anymore to avoid irreparable tearing of the diaphragm!

    -Service or testing with compressed air or gas is not recommended.
