G41F-6S - BAODI PPH WEIR FLANGED DIAPHRAGM VALVE

Price: Contact

  • Model: G41F-6S
  • Trademark: BAODI
  • Origin: China
  • PPH WEIR FLANGED DIAPHRAGM VALVE

    • Media: Chemical, acid, water, oil, etc.
    • Actuator: Manual
    • Connection: Flanged Diaphragm Valve
    • Material: Plastic(Pph)
    • Structure: Weir Diaphragm Valve
    • Standard: DIN, GB, ANSI, JIS
    • Size: Dn15-Dn250(1/2′′-10′′)
    • Temperature: Ordinary Temperature
    • Model NO.: G41F-6S
    • Pressure: Low Pressure
    • Flow Direction: Bidirectional
    • Usage: Flow Control
    • Standard: DIN, GB, ANSI, BSW, JIS
    • Size: Dn15-Dn300
    • Trademark: Baodi
    • Transport Package: Carton
    • Origin: China
    • HS Code: 8481804090
    • Function: Intelligent Type/Field Bus
    • Working temperature: PPH- ~14ºC- 90ºC



    PPH WEIR FLANGED DIAPHRAGM VALVE DETAILS

    Diaphragm valve material app temperature bound

    The datas are updating. Please contact our sales for more details

    Material

    Medium temperature

    Material

    Medium temperature

    FRPP

    -20℃~ +90℃

    PVDF

    -40℃~ +120℃

    UPVC

    -40℃ ~ +60℃

    CPVC

    -40℃ ~ +95℃



    Part material list

    The datas are updating. Please contact our sales for more details

    No.

    Name

    Material

    No.

    Name

    Material

    NO.

    Name

    Material

    1

    Stud

    Steel, Stainless Steel

    8

    YokeNut

    HT300 Steel

    15

    Flim

    EPDM.IIR

    2

    Indicator

    Steel

    9

    Stem

    Steel, Stainless Steel

    16

    Diaphragm

    F46.PFA.
    PVDF.PTFE

    3

    Stopcover

    PC.AS

    10

    Bonnet

    FRPP,PVDF

    UPVC,CPVC

    17

    Pin

    Steel, Stainless Steel

    4

    Washer

    Steel, Stainless Steel

    11

    Flat bearing

    Ball beraing

    18

    Disc

    Steel, Stainless C.I.FRP

    5

    Wheel

    ABS

    12

    Nut

    Steel, Stainless Steel

    19

    Diaphragm

    F46

    6

    RetainingNut

    FRPP Steel, Stainless Steel

    13

    Stud

    Sted, Stainless Steel



    7

    Liningring

    PP

    14

    Body

    FRPP, PVDF UPVC, CPVC
