ROUND THERMOPLASTIC UPVC PIPE

Price: Contact

  • Model:
  • Trademark: BAODI
  • Origin: China
    • Project details Download Catalogue Evaluate

    ROUND THERMOPLASTIC UPVC PIPE

    • Material: UPVC
    • Size: DN15-300(1/2''--12'')
    • Pressure: 10bar
    • Other Material: CPVC, PVDF, PPH, FRPP
    • Shape: Equal
    • Media: Chemical, acid, alkali, water, oil, food, waste water...
    • Standard: GB
    • Diameter: Dn15mm-300mm
    • Medium: Liquid/Gas/Water/Solution/Oil
    • Cross-Section Shape: Round/Semi-Circular
    • Temperature Classification: Medium Temperature Piping
    • MPa Classfication: Low Pressure Piping
    • Connection Type: Socket
    • Hardness: Hard Tube
    • Type: Thermoplastic Pipe
    • Color: Color
    • Hollow: Hollow
    • Shape: Round
    • Specification: DN: 15-400mm
    • Origin: China
    • HS Code: 3917230000
    • Usage: Drainpipe, Water Supply Pipe, Agricultural Irrigation Pipe, Chemical
    • Pipe Length: UPVC/CPVC-4m FRPP/PPH/PVDF-5m
    • Working temperature: UPVC- ~40ºC-+60ºC

    ROUND THERMOPLASTIC UPVC PIPE DETAILS

    CPVC UPVC PIPE



    The datas are updating. Please contact our sales for more details

    DN(mm) Noninal diameter

    D(mm) Nominal outer diameter

    L(mm) Length

    1.6Mpa

    1.6Mpa

    1.0Mpa

    1.0Mpa
    CPVC UPVC CPVC UPVC CPVC UPVC

    15

    20

    20

    4000

    2.0+0.2

    2.0+0.2



    20

    25

    25

    4000

    2.0+0.3

    2.0+0.3



    25

    32

    32

    4000

    2.4+0.3

    2.4+0.3



    32

    40

    40

    4000

    3.0+0.4

    3.0+0'4



    40

    50

    50

    4000

    3.7+0.4

    4.7+0.4



    50

    63

    63

    4000

    4.7+0.4

    4.7+0.4



    65

    75

    75

    4000

    5.6+0.4

    5.6+0.4



    80

    90

    90

    4000

    6.7+0.4

    6.7+0.4



    100

    110

    110

    4000

    8.1+0.4

    8.1+0.4



    125

    140

    140

    4000

    10.3+0.4

    10.3+0.4

    6.7+0.4

    6.7+0.4

    150

    160

    160

    4000

    11.8+0.5

    11.8+0.S

    7.7+0.5

    7.7+0.5

    200

    225

    225

    4000



    10.8+0.6

    10.8+0.6

    250

    280

    280

    4000



    15.0+0.7

    13.4+0.7

    300

    315

    315

    4000



    17.5+0.8

    15.0+0.8

    350

    355

    355

    4000



    18.3+0.8

    16.9+0.8

    400

    400

    400

    4000



    21.0+0.9

    19.1+0.9

    If needs the non-standard tubing,the fitting according to the pattern manufacture.



    Tubing size comparative table

    The datas are updating. Please contact our sales for more details

    API

    JIS

    Metric system
    1/2"(21.3)

    16(22)

    15(20)
    3/4"(26.7)

    20(26)

    20(25)
    1"(33.4)

    25(32)

    25(32)
    l 1/4"(42.2)

    30(38)

    32(40)
    1 1/2"(48.3)

    40(48)

    40(50)
    2"(60.3)

    50(60)

    50(63)
    2 1/2"(73)

    65(76)

    65(75)
    3"(88.9)

    75(89)

    80(90)
    4"(114.3)

    100(114)

    100(110)
    5"(141.3)

    125(140)

    125(140)
    6"(168.3)

    150(165)

    150(160)
    8"(219.1)

    200(216)

    200(225)
    10"( 273.1)

    250(265)

    250(280)
    12"(329.9)

    300(318)

    300(315)
    16"( 406.4)

    400(420)

    400(400)
