YBJ-4W(For Steam) - Bellows Type Expansion Pipe Joint- Double type - socket - welded type

㉿Mark inscription allowed product/ Korea register of ahipping model approval


This is used to absorb the axialdirection expansion and contraction of a pipeline that occurs according to temperature changes. Since it is an internal pressure type, it is buckling-free and ensures smooth expansion/contraction.

Features

• Absorb the expansion & contraction of pipelines by temperature changes.
• Outstanding level of corrosion resistance : Parts materials come into contact with fluid are made of stainless steel.
• Outer tube has been used to prevent damage to the bellows from impact

Specification:

• Type: YBJ-4W(For Steam)
• Structure: Double type
• Applicable fluid: Cold/hot water, Oil, Air, Steam
• Applicable pressure : Maximum 1.0MPa
• Fluid temperature: 220°C below
• Expansion/contraction: length 70mm
• End connection: KS D 3507 Dimensions-based socket-welded type
• Materials:
  • Bellows, Inner tube: STS
  • Outer tube: SPP
  • Socket: SPP
• Hydraulic test pressure: 1.5MPa

▶ The fixing bolt should be loosened after the hydro-pressure test.

▶ Custom made for steam.
