Bellows Type Expansion Pipe Joint

YBJ-4S(For Water) - Bellows Type Expansion Pipe Joint- Single type - socket - welded type

Price: 916,000 d

  • Model: YBJ-4S(For Water)
  • Trademark: SAMYANG
  • Origin: Korea
  • Size: DN20
  • YBJ-4S(For Water) - Bellows Type Expansion Pipe Joint - Single type - socket - welded type

    ㉿Mark inscription allowed product/ Korea register of ahipping model approval


    This is used to absorb the axialdirection expansion and contraction of a pipeline that occurs according to temperature changes. Since it is an internal pressure type, it is buckling-free and ensures smooth expansion/contraction.

    Features

    • Absorb the expansion & contraction of pipelines by temperature changes.
    • Outstanding level of corrosion resistance : Parts materials come into contact with fluid are made of stainless steel.
    • Outer tube has been used to prevent damage to the bellows from impact



    Specification:

    • Type: YBJ-4S(For Water)
    • Structure: Single type
    • Applicable fluid: Cold/hot water, Oil, Air, Steam
    • Applicable pressure : Maximum 1.0MPa
    • Fluid temperature: 220°C below
    • Expansion/contraction: length 35mm
    • End connection: KS D 3507 Dimensions-based socket-welded type
    • Materials:
      • Bellows, Inner tube: STS
      • Outer tube: SPP
      • Socket: SPP
    • Hydraulic test pressure: 1.5MPa

    ▶ The fixing bolt should be loosened after the hydro-pressure test.

    ▶ Custom made for steam.
