Bellows Type Expansion Pipe Joint

YBJ-3W(For Water) - Bellows Type Expansion Pipe Joint - Double type - socket - welded type

Price: 3,324,000 d

  • Model: YBJ-3W(For Water)
  • Trademark: SAMYANG
  • Origin: Korea
  • Size: DN20
  • YBJ-3W(For Water) - Bellows Type Expansion Pipe Joint - Double type - socket - welded type

    ㉿Mark inscription allowed product/ Korea register of ahipping model approval


    This is an expansion pipe joint used for cold water, hot water, or other copper pipelines

    Features

    • Absorb the expansion & contraction of pipelines by temperature changes.
    • Stainless steel ensuring high level of corrosion resistance leads little fluid pressure loss : Inner tube materials which come into contact with fluid are made of stainless steel.
    • Outer tube has been used to prevent damage to bellows from impact.
    • Internal pressure type product prevents noise.



    Specification:

    • Type: YBJ-3W(For Water)
    • Structure: Double type
    • Applicable fluid: Cold/hot water, Oil, Air
    • Applicable pressure: Maximum 1.0MPa
    • Fluid temperature: 220°C below
    • Expansion/contraction: length 70mm
    • End connection: KS D 5578 Dimensions-based socket-welded type
    • Materials
      • Bellows, Inner tube: STS
      • Outer tube: SPP
      • Socket: CuT
    • Hydraulic test pressure: 1.5MPa


    ▶ The fixing bolt should be loosened after the hydro-pressure test.

    ▶ Custom made for steam.
