Bellows Type Expansion Pipe Joint

JSY-9B - Flexible Tube Flange JIS10K

Price: 1,151,000 d

  • Model: JSY-9B(10K)
  • Trademark: SAMYANG
  • Origin: Korea
  • Size: DN25
  • JSY-9B - Flexible Tube Flange JIS10K

    Features

    • This product has a short distance among the surfaces and has a structure that allows it to absorb an extensive expansion/contraction length, making it especially ideal for pump connectors.



    Specification:

    • Applicable fluid: Cold/hot water, Oil, Air, Steam
    • Maximum running pressure: Maximum 1.0MPa
    • Maximum applicable temperature: 220°C below
    • End connection: KS 10K FF FLANGE
    • Materials
      • BELLOWS: STS
      • FLANGE: SS400
    • Hydraulic test pressure: 1.5MPa / 3.0MPa
