Bellows Type Expansion Pipe Joint

YBJ-2W(For Water) - Bellows Type Expansion Pipe Joint - Double type - JIS20K

Price: 2,643,000 d

  • Model: YBJ-2W(For Water)
  • Trademark: SAMYANG
  • Origin: Korea
  • Size: DN25
  • YBJ-2W(For Water) - Bellows Type Expansion Pipe Joint - Double type - JIS20K

    ㉿Mark inscription allowed product/ Korea register of ahipping model approval


    The KS B 1536 bellows type expansion pipe joint is mainly used for cooling, heating, airconditioning, and sanitary pipelines. It is an expansion pipe joint that absorbs the axialdirection expansion and contraction of a pipe that occurs according to temperature changes.

    Features

    • Standards of the Korean Industrial Standard (KS B 1536), the Association of the United States Army, and the Korean Register of Shipping (KR).
    • Offer strong & outstanding level of corrosion resistance & durability : Parts material come into contact with fluid are made of stainless steel and have been molded.
    • Outer tube has been used to prevent damage to bellows from outside impact.
    • Inner tube adoption ensures little pressure loss of fluid, smooth flow & long life span.



    Specification:

    • Type: YBJ-2W(For Water)
    • Structure: Double type
    • Applicable fluid: Cold/hot water, Air, Gas, Oil
    • Applicable pressure : Maximum 2.0MPa
    • Fluid temperature : 250°C below
    • Expansion/contraction:  lenght 70mm
    • End connection: KS 20K RF Flange
    • Materials
      • Bellows, Inner tube: STS
      • Outer tube: SPP
      • Flange: SS400
    • Hydraulic test pressure 3.0MPa



    ▶ Do not couple this product with a copper pipeline.

    ▶ 350A or larger are available by made-to-orders.

    ▶ Those used for ANSI #125, #150, #300, and steel flanges are available by made-to-orders.

    ▶ The fixing bolt should be loosened after the hydro-pressure test.

    ▶ Over 250A is KS 10K FF Flange. ▶ Custom made for steam.
