YBJ-3S(For Steam) - Bellows Type Expansion Pipe Joint - Single type - socket - welded type

㉿Mark inscription allowed product/ Korea register of ahipping model approval


This is an expansion pipe joint used for cold water, hot water, or other copper pipelines

Features

• Absorb the expansion & contraction of pipelines by temperature changes.
• Stainless steel ensuring high level of corrosion resistance leads little fluid pressure loss : Inner tube materials which come into contact with fluid are made of stainless steel.
• Outer tube has been used to prevent damage to bellows from impact.
• Internal pressure type product prevents noise.

Specification:

• Type: YBJ-3S(For Steam)
• Structure: Single type
• Applicable fluid: Cold/hot water, Oil, Air
• Applicable pressure: Maximum 1.0MPa
• Fluid temperature: 220°C below
• Expansion/contraction: length 30mm
• End connection: KS D 5578 Dimensions-based socket-welded type
• Materials
  • Bellows, Inner tube: STS
  • Outer tube: SPP
  • Socket: CuT
• Hydraulic test pressure: 1.5MPa

▶ The fixing bolt should be loosened after the hydro-pressure test.

▶ Custom made for steam.
