Pressure Reducing Valve

COS-3/16/21 - Pressure Reducing Valves for Process Steam (with Built-in Separator & Trap)

Price: Contact

Model: COS-3, COS-16, COS-21

Trademark: TLV

Origin: Japan

Order

Project details Download Catalogue Evaluate

Pressure Reducing Valves for Process Steam (with Built-in Separator & Trap)

DOWNLOAD CATALOG (COSPECT® Pressure Reducing Valves Pamphlet)

Troublefree Pressure Reducing Valves

COSPECT®’s built-in strainer, Super Cyclonical Effects Separator (SCE) and Free Float® steam trap help prevent scale, rust and condensate from entering the pressure reducing valve (PRV) or reaching the important interior parts.

In particular, the cyclone separator forcibly removes 98% of the condensate from the flow at the inlet side, thereby greatly reducing condensate-induced erosion of parts such as the main valve.

While the standard service life of a PRV for steam is often less than a few years, many TLV COSPECT® users are still using their COSPECT® PRVs more than 10 years after installation. Such long service life is a testimony to COSPECT®'s effectiveness in countering scale and condensate, some of the most common sources of problems for PRVs in steam systems.

Benefits and Features

Improved Quality of Material Being Heated
- Delivers Stable Pressure
  Achieves secondary pressure accuracy within ±0.01 MPa of the set level. Even if the steam flow (load) to the equipment or the primary pressure at the pressure reducing valve changes, the Shock-Absorbing Spherical Piston (SAS) supplies steam at a constant pressure in order to prevent temperature fluctuation downstream.
- Supplies Dry Steam
  The built-in Cyclone Separator removes condensate from steam with a condensate separation efficiency of 98%. Condensate entrained in the steam is removed, and a strainer further removes any scale. The condensate that is separated out is discharged through the built-in Free Float® steam trap.
  The increased quality of the steam contributes to improved heat conductivity.

Easy to Adjust
- Pressure adjustment is simple; just use the cover cap as the adjustment spanner.

Long Service Life
- Rust presents a high risk to vital areas of the system. To eliminate this, all major valve components are made of stainless steel to prevent rust and corrosion. Additionally, the inclusion of a strainer in the piping installation prevents the inflow of rust and other debris, protecting the valve components and contributing to a long service life.

Application Areas

Recommended for processes requiring steam at a stable pressure and processes such as atomizers in which steam comes into direct contact with the product.

Reactor kettles,
Dryers,
Heat exchangers,
Presses,
Steamers
Blowers
Atomizers, etc.

Product Details

Model	Connection	Body Material	PMO (MPaG)	TMO (°C)	Primary Pressure (MPaG)	Secondary Pressure (MPaG)	Max. Flow Capacity (kg/h)	Specifications	Manual
COS-3	Screwed	Cast Iron (FC250)	0.3	220	0.1 - 0.3	0.01 - 0.05	950	Specification	Contact us
COS-3	Flanged	Cast Iron (FC250)	0.3	220	0.1 - 0.3	0.01 - 0.05	950	Specification	Contact us
COS-16	Screwed	Cast Iron (FC250)	1.6	220	0.2 - 1.6	0.03 - 1.34	19,800	Specification	Contact us
COS-16	Flanged	Cast Iron (FC250)	1.6	220	0.2 - 1.6	0.03 - 1.34	19,800	Specification	Contact us
COS-21	Screwed	Ductile Cast Iron (FCD450)	2.1	220	1.35 - 2.1	0.55 - 1.75	19,000	Specification	Contact us
COS-21	Flanged	Ductile Cast Iron (FCD450)	2.1	220	1.35 - 2.1	0.55 - 1.75	19,000	Specification	Contact us
