Pressure reducing valves for vacuum steam, with built-in separator & trap

Improved Quality of Material Being Heated

• Supplies steam at a stable pressure.
  Accuracy of reducing valve's secondary set pressure is within ± 0.01 MPa. Even if the steam flow (load) to the equipment or the primary pressure at the reducing valve changes, the Shock-absorbing Spherical piston (SAS) supplies steam at a constant pressure in order to maintain the temperature of the steam used as the heating source.
• Supplies dry steam.
  Product features a built-in Cyclone Separator with a 98% condensate separation efficiency. The separator improves the dryness of the steam and removes scale entrained in the steam. The condensate that is separated out is quickly removed through the built-in Free Float® steam trap.
  This improvement in the quality of the steam itself also results in an improvement in the heat conductivity of the steam.

Easy to Adjust

• Pressure adjustment is simple, and can be done by using the cover cap as the adjustment spanner.

Long Service Life

• Rust presents a high risk to vital areas of the system. To eliminate this, all major valve components are made of stainless steel to prevent rust and corrosion. Additionally, the inclusion of a strainer in the piping installation prevents the inflow of rust and other debris, protecting the valve components and contributing to a long service life.

Application Areas

Can be used in a variety of steam heating equipment that supplies steam at temperatures of 100 ºC or less.

• Concentration kettles
• Reactor kettles
• Heat exchangers
• Presses
• Dryers, etc.
