BROADY TYPE C3

REDUCING/REGULATING VALVE

The Broady Type C3 self acting pressure reducing/regulating valve is available in sizes 15NB to 100NB with a maximum inlet pressure of 21 barg and a reduced pressure range of 0.35 barg to 8.30 barg. The valve is suitable on steam, air, gas and liquid applications.

Below is a brief summary of our Type C3 Pressure Reducing/Regulating Valve.

​

Sizes

15NB to 100 NB​

​

Flanges

In accordance with ASME B16.5, DIN EN 1092-1 or JIS 2220

(Other standards/options available upon request)

​

Screwed Connections

NPT or BSP

​

Material

Gunmetal, Stainless Steel, Aluminium Bronze and Duplex Stainless Steel

​

Maximum Inlet Pressure

17.50 Barg (Steam)

21.00 Barg (Gas & Liquid)

​

Reduced Pressure Range

0.35 Barg to 8.30 Barg

​

Medium

Steam, air, gas and liquid applications

​

​​
