Type W1

Broady Reducing/Regulating valve

The Broady Type W1 balanced inlet high capacity pressure reducing/regulating valve is available in sizes 15NB to 150NB with a maximum inlet pressure of 20 barg and a reduced pressure range of 0.50 barg to 10.00 barg. The valve is suitable on gas and liquid applications.

Below is a brief summary of our Type W1 Pressure Reducing/Regulating Valve.

​

Sizes

15NB to 150 NB​

15NB to 50NB (Screwed)

​

Flanges

In accordance with ASME B16.5, DIN EN 1092-1 or JIS 2220

(Other standards/options available upon request)

​

Screwed Connections

NPT or BSP

​

Material

SG Iron, Carbon Steel and Stainless Steel

​

Maximum Inlet Pressure

20.00 Barg

​

Reduced Pressure Range

0.50 Barg to 10.00 Barg

​

Medium

Gas and liquid applications

​

If further assistance is required please contact our sales team on +842835352125 - 0902720814 - 0907450506 - 0902800728 - 0766226161 or email info@pm-e.vn
