BROADY TYPE D

REDUCING/REGULATING VALVE

The Broady Type D balanced inlet high capacity pressure reducing/regulating valve is available in sizes 15NB to 200NB with a maximum inlet pressure of 20 barg and a reduced pressure range of 0.35 barg to 13.80 barg. The valve is suitable on liquid applications.

Below is a brief summary of our Type D Pressure Reducing/Regulating Valve.

​

Sizes

15NB to 200 NB​

15NB to 50NB (Screwed)

​

Flanges

In accordance with ASME B16.5, DIN EN 1092-1 or JIS 2220

(Other standards/options available upon request)

​

Screwed Connections

NPT or BSP

​

Material

Gunmetal, SG Iron, Aluminium Bronze and Stainless Steel

​

Maximum Inlet Pressure

20.00 Barg

(High pressure design for inlet up to 45.00 Barg available on request)

​

Reduced Pressure Range

0.35 Barg to 13.80 Barg

​

Medium

Liquid applications

​

​​

If further assistance is required please contact our sales team on +842835352125 - 0902720814 - 0907450506 - 0902800728 - 0766226161 or email info@pm-e.vn
