BROADY TYPE B2

REDUCING/REGULATING VALVE

The Broady Type B2 pilot operated steam pressure reducing/regulating valve is available in sizes 15NB to 150NB with a maximum inlet pressure of 28 barg and a reduced pressure range of 0.35 barg to 17.50 barg. The valve is suitable on steam, air and gas applications.

Below is a brief summary of our Type B2 Pressure Reducing/Regulating Valve.

​

Sizes

15NB to 150 NB​

​

Flanges

In accordance with ASME B16.5, DIN EN 1092-1 or JIS 2220

(Other standards/options available upon request)

​

Screwed Connections

NPT or BSP

​

Material

SG Iron, Carbon Steel and Stainless Steel

​

Maximum Inlet Pressure

28.00 Barg (15NB to 25NB)

25.00 Barg (32NB to 50NB)

21.00 Barg (65NB to 150NB)

​

Reduced Pressure Range

0.35 Barg to 17.50 Barg

​

Medium

Steam, air and gas applications

​

​
