BROADY TYPE C4 FIG 3

REDUCING/REGULATING VALVE

The Broady Type C4 Fig 3 self acting high pressure reducing/regulating valve is available in sizes 6NB to 100NB with a maximum inlet pressure of 345 barg and a reduced pressure range of 1.00 barg to 70.00 barg. The valve is suitable on steam, air, gas and liquid applications.

Below is a brief summary of our Type C4 Fig 3 Pressure Reducing/Regulating Valve.

​

Sizes

6NB to 100 NB​

6NB to 32NB (Screwed)

​

Flanges

In accordance with ASME B16.5, DIN EN 1092-1 or JIS 2220

(Other standards/options available upon request)

​

Screwed Connections

NPT or BSP

​

End Connections

Butt Weld and Socket Weld Ends available

​

Material

Carbon Steel, Stainless Steel, Gunmetal, Duplex Stainless Steel

​

Maximum Inlet Pressure

345.00 Barg (6NB to 25NB)

138.00 Barg (32NB to 100 NB)

​

Reduced Pressure Range

1.00 Barg to 7.00 Barg

(Special designs for higher outlet pressures available on request)

​

Medium

Steam, air, gas and liquid applications

​

​​
