Ball, Slip, Multi Joint

SIS/SID Type Slip Joint

Price: Contact

  • Model: SIS/SID Type
  • Trademark: SAMYANG
  • Origin: Korea
  • Size: DN32
  • SIS/SID Type Slip Joint

    As an injection packing type, it absorbs one-way (two-way) displacements and is applied for thermal expansion and contraction. Maintenance can be made during operation, thanks to injection packing

    Features

    • Injection packing type double slip joint.
    • Absorb straight line direction displacements: It can be used for extremely high-temperature fluid.
    • Internal & external guide structure : It has longer life span than other conventional slip joints.
    • External guide with outstanding lubrication ensures smooth slip.
    • Safe packing injection is available under internal pressure

    Specification:

    • Type: SIS Single Type & SID Double Type
    • Applicable fluid: Saturated Steam, Superheat Steam, Oil, Water, Gas
    • Maximum running pressure: 1.0, 2.0, 3.0MPa
    • Maximum applicable temperature: 250℃ (Order over 250℃ or more)
    • Materials
      • Body: CAC304, STS, SPPS, SCPH2, GCD
      • Sleeve: CAC304, STS, SC480
      • Packing: Grafoil (SI NO.800)

    ▶ The live loading method and dust-cover attachment are available by made-to-orders
