SGS/SGD Type Slip Joint

As a grand packing type, this absorbs one-way direction (twoway direction) displacements, and is applied for thermal expansion and contraction. Thanks to the adoption of the live loading method, simple maintenance is ensured.

Features

• Injection packing type single slip joint.
• Absorb displacements in a straight line direction.
• Internal & external guide structure has longer life span than other conventional slip joints.
• External guide with outstanding lubrication ensures smooth slip.
• Highly resistant to pipeline vibration & distortions by adopted live loading method.

Specification:

• Type: SGS Single Type & SGD Double Type
• Applicable fluid: Saturated Steam, Superheat Steam, Oil, Water, Gas
• Maximum running pressure: 1.0, 2.0,3.0MPa
• Maximum applicable temperature: 250°C (Special orders are available for 250°C)
• Materials
  • Body: CAC304, STS, SPPS, SCPH2, GCD
  • Sleeve: CAC304, STS, SC480
  • Packing: Teflon+Grafoil (SI NO.800)

▶ The live loading method and dust-cover attachment are available by made-to-orders
