BSI Multi Joint

As an injection packing type, this product absorbs omni-directional displacements, and is applied for thermal expansion and contraction. Maintenance can be made during operation, thanks to injection packing

Features

• Functions combined ball and slip joint, effectively uses both strengths.
• Absorb pipeline expansion & contraction which results from thermal expansion.
• Protect pipelines, buildings, facilities, etc. from ground damage.
• Used for hydraulic equipment, petrochemicals, mines, agricultural sites, cable facilities, and various plants.
• Absorb high-rise building's sway & building shortening.

Specification:

• Applicable fluid: Saturated Steam, Superheat Steam, Oil, Water, Gas
• Maximum running pressure: 1.0, 2.0, 3.0MPa
• Maximum applicable temperature: 250°C (Special orders are available for 250°C or higher)
• Materials
  • Body: STS, SPPS, SCPH2, GCD
  • Slip/Ball: STS, SC480
  • Packing: Grafoil (SI NO.800}
