EX (SER.10) MODEL

Uni-directional wafer style knife gate valve for general industrial applications

The EX model knife gate valve is a uni-directional wafer valve designed for general industrial service applications. The design of the body and seat assures non-clogging shutoff on suspended solids in industries such as:

• Pulp and Paper
• Power plants
• Wastewater treatment plants
• Chemical plants
• Food and Beverage
• Bulk handling
• Mining
• etc.

SIZES

DN 50 to DN 1200 (larger diameters on request)

WORKING PRESSURE

DN 50 to DN 250: 10 bar
DN 300 to DN 400: 6 bar
DN 450: 5 bar
DN 500 to DN 600: 4 bar
DN 700 to DN 1200: 2 bar

STANDARD FLANGE CONNECTION

EN1092 PN10
ASME B16.5 (class 150)

OTHER  FLANGE CONNECTION (ON REQUEST)

EN1092 PN6/16/25
BS D and E ASME 125

DIRECTIVES

For EU Directives and other Certificates please see the document: Directives & Certificates Compliance - Knife Gate Valves – Catalogues and Datasheets
