EK MODEL

Uni-directional high performance wafer style knife gate valve for general industrial applications

The EK model knife gate is a uni-directional wafer valve designed for general industrial service applications. The design of the body and seat assures non-clogging shutoff on suspended solids in industries such as:

• Pulp and Paper
• Power plants
• Wastewater treatment plants
• Chemical plants
• Food and Beverage
• Bulk handling
• Mining
• etc.

SIZES

DN 50 to DN 1200 (larger diameters on request).

WORKING PRESSURE

DN 50 to DN 125: 16 bar
DN 150 to DN 250: 10 bar
DN 300 to DN 400: 6 bar
DN 450: 5 bar ⁽¹⁾
DN 500 to DN 600: 4 bar⁽¹⁾
DN 700 to DN 1200: 2 bar

⁽¹⁾6 bar with duplex gate

STANDARD FLANGE CONNECTION

EN1092 PN10 and ASME B16.5 (class 150).

OTHER FLANGE CONNECTION (ON REQUEST)

EN1092 PN6/16/25
BS "D" and "E"
ASME 125

DIRECTIVES

For EU Directives and other Certificates please see the document: Directives & Certificates Compliance - Knife Gate Valves – Catalogues and Datasheets
