BT (SER.22) MODEL

Bi-directional MSS SP-81 lug type knife gate valve for general industrial and water applications

The BT model knife gate is a bi-directional lug type valve designed according to MSS-SP-81 and TAPPI TIS 405-8 for industrial service applications. The design of the body and seat assures non-clogging shut off on suspended solids in industries such as:

• Pulp and Paper
• Power plants
• Mining
• Chemical plants
• Wastewater
• Food and Beverage
• etc.

SIZES

DN 2"/50 to DN 36”/900 (larger diameters on request)

WORKING PRESSURE

DN 2"/50 to DN 24”/600: 150psi / 10 bar
DN 30"/750: 100psi / 7 bar
DN 36"/900: 100psi / 7 bar

STANDARD FLANGE CONNECTION

ASME B16.5 (class 150)

OTHER FLANGE CONNECTION (ON REQUEST)

DIRECTIVES

For EU Directives and other Certificates please see the document: Directives & Certificates Compliance - Knife Gate Valves – Catalogues and Datasheets
